Release Info
| Catalog ID |
TGN-004-GL |
| Region |
USA (NTSC) |
| Class |
Unlicensed |
| Release Date |
1989 |
| Publisher |
Tengen |
| Developer |
Tengen |
| Players |
2 |
| Peripherals |
NES Controller |
Cart Properties
| Cart Producer |
Tengen |
| Color |
Black |
| Form Factor |
Original |
| Embossed Text |
|
| Front Label ID |
|
| Seal of Quality |
|
| MfgString Present |
|
| 2-digit Code |
|
PCB Properties
| Name |
800004-01 REV C |
| PCB Producer |
Tengen |
| Manufacturer |
Key Tronic |
| Mfg Range |
8850 - 9114 (3) |
| Est First Run |
December 1988 |
| PCB Class |
TENGEN-800004 |
| iNES Mapper |
206 |
| Mirroring |
Four Screen |
| Battery present |
No |
| WRAM |
0 KB |
| VRAM |
2 KB |
| CIC Type |
337002 |
| Hardware |
337001, 74xx00 |
ROM Details
| Type |
Label |
Size |
CRC32 |
x ! |
| PRG0 |
335004-1011 |
128 KB |
B19C48A5 |
3 |
| CHR0 |
335004-1012 |
64 KB |
1EEFF226 |
3 |
| N/A |
ROMs Combined |
192 KB |
CD50A092 |
3 |
Detailed Chip Info
| Designation |
Maker |
Part # |
Type |
Package |
Date Code |
Std |
Misc |
Additional Images
PCB Images
