Release Info
| Catalog ID | UNL-RCMII |
|---|---|
| Region | USA (NTSC) |
| Class | Unlicensed |
| Release Date | March 22, 1996 |
| Publisher | RacerMate |
| Developer | RacerMate |
| Players | 2 |
| Peripherals | RacerMate Bike |
Cart Properties
| Cart Producer | Tengen |
|---|---|
| Color | Black |
| Form Factor | Original |
| Embossed Text | |
| Front Label ID | |
| Seal of Quality | |
| MfgString Present | |
| 2-digit Code |
PCB Properties
| Name | R981-112-00 |
|---|---|
| PCB Producer | |
| Manufacturer | Not Specified |
| Mfg Range | 9016 - 9648 (3) |
| Est First Run | April 1990 |
| PCB Class | UNL-RACERMATE |
| iNES Mapper | 168 |
| Mirroring | Horizontal |
| Battery present | Yes |
| WRAM | 0 KB |
| VRAM | 64 KB |
| CIC Type | 337002 |
| Hardware | 74xx00, 74xx00, 74xx174, 74xx174, 74xx32, 74xx32, 74xx4040 |
ROM Details
| Type | Label | Size | CRC32 | x ! |
|---|---|---|---|---|
| PRG0 | N311088 05/15/91 | 64 KB | 74920C13 | 1 |
Detailed Chip Info
| Designation | Maker | Part # | Type | Package | Date Code | Std | Misc |
|---|---|---|---|---|---|---|---|
| U1 | Harris | CDM62256E10 | SRAM 32 KB | DIP-28 | 923 | 8923 | |
| U10 | Harris | CD74HC4040E | 74-4040 Series | DIP-16 | 9014 H | 9014 | |
| U11 | Motorola | 337002-001 | Tengen CIC | DIP-16 | 8906 ILZA | 8906 | |
| U2 | Harris | CDM62256E10 | SRAM 32 KB | DIP-28 | 923 | 8923 | |
| U3 | Microchip | 27C512-20 | UV EPROM 64 KB | DIP-28 | 8944 CTD | 8944 | |
| U4 | Harris | CD74HC174E | 74-174 Series | DIP-16 | 8949 H. | 8949 | |
| U5 | Hitachi | HD74HC32P | 74-32 Series | DIP-14 | 6F3 T | 8625 | |
| U6 | Phillips | 74HC00N | 74-00 Series | DIP-14 | 8905 KC | 8905 | KFZ7874 |
| U7 | Hitachi | HD74HC32P | 74-32 Series | DIP-14 | 6F3 T | 8625 | |
| U8 | Phillips | 74HC00N | 74-00 Series | DIP-14 | 8905 KC | 8905 | KFZ7874 |
| U9 | Motorola | MC74HC74AN | 74-174 Series | DIP-16 | 9016 FFPD | 9016 |
