Release Info
| Catalog ID | TCF-SZ |
|---|---|
| Region | Japan (NTSC) |
| Class | Licensed |
| Release Date | January 24, 1992 |
| Publisher | Tecmo |
| Developer | Tecmo |
| Players | 1 |
| Peripherals | Famicom Controller |
Cart Properties
| Cart Producer | Nintendo (Famicom) |
|---|---|
| Color | Aquamarine |
| Form Factor | Small |
| Embossed Text | |
| Front Label ID | TCF-SZ |
| Seal of Quality | |
| MfgString Present | |
| 2-digit Code | 09 |
PCB Properties
| Name | HVC-TKROM-03 |
|---|---|
| PCB Producer | Nintendo |
| Manufacturer | Not Specified |
| Mfg Range | 9151 |
| Est First Run | December 1991 |
| PCB Class | HVC-TKROM |
| iNES Mapper | 4 |
| Mirroring | Mapper Ctrl |
| Battery present | Yes |
| WRAM | 8 KB |
| VRAM | 0 KB |
| CIC Type | None |
| Hardware | MMC3B |
ROM Details
| Type | Label | Size | CRC32 | x ! |
|---|---|---|---|---|
| PRG0 | TCF-SZ-0 PRG | 128 KB | C71E77CA | 1 |
| CHR0 | TCF-SZ-0 CHR | 128 KB | 3E1D8F0D | 1 |
| N/A | ROMs Combined | 256 KB | EEE6314E | 1 |
Detailed Chip Info
| Designation | Maker | Part # | Type | Package | Date Code | Std | Misc |
|---|---|---|---|---|---|---|---|
| U1 PRG | NEC | 23C1010BCZ W72 | Mask ROM 128 KB | DIP-28 | 9151 K9008 | 9151 | |
| U2 CHR | NEC | 23C1013BCZ W60 | Mask ROM 128 KB | DIP-32 | 9150 KY008 | 9150 | |
| U3 MMC3 | Sharp | MMC3B | Nintendo MMC3 | TQFP-44 | 9149 5 AB | 9149 | |
| U4 W-RAM | Sanyo | LC3564PL-12 | SRAM 8 KB | DIP-28 | 14 126 | 9114 |
