Release Info
| Catalog ID |
KON-RV003 |
| Region |
Japan (NTSC) |
| Class |
Licensed » 3rd-Party |
| Release Date |
February 5, 1993 |
| Publisher |
Konami |
| Developer |
Konami |
| Players |
1 |
| Peripherals |
Famicom Controller |
Cart Properties
| Cart Producer |
Konami |
| Color |
Black |
| Form Factor |
Small |
| Embossed Text |
|
| Front Label ID |
RV003 |
| Seal of Quality |
|
| MfgString Present |
|
| 2-digit Code |
|
PCB Properties
| Name |
353525 |
| PCB Producer |
Konami |
| Manufacturer |
Not Specified |
| Mfg Range |
9302 |
| Est First Run |
January 1993 |
| PCB Class |
KONAMI-UNROM |
| iNES Mapper |
2 |
| Mirroring |
Vertical |
| Battery present |
No |
| WRAM |
0 KB |
| VRAM |
8 KB |
| CIC Type |
None |
| Hardware |
74xx161, 74xx32 |
ROM Details
| Type |
Label |
Size |
CRC32 |
x ! |
| PRG0 |
RV 003 J00P |
128 KB |
A0F99BB8 |
1 |
Detailed Chip Info
| Designation |
Maker |
Part # |
Type |
Package |
Date Code |
Std |
Misc |
|
Panasonic |
MN231001
|
Mask ROM
128 KB
|
DIP-28 |
314
53
|
9302 |
|
|
Sharp |
LH5168D-10L
|
SRAM
8 KB
|
SDIP-28 |
9209
3 SB
|
9209 |
|
|
Fujitsu |
MB74LS161A
|
74-161 Series
|
DIP-16 |
8737
W04
|
8737 |
|
|
Motorola |
SN74LS32N
|
74-32 Series
|
DIP-14 |
9247
JJBD
|
9247 |
|
Additional Images
PCB Images
