Release Info
| Catalog ID | KON-RC851 |
|---|---|
| Region | Japan (NTSC) |
| Class | Licensed » 3rd-Party |
| Release Date | April 26, 1991 |
| Publisher | Konami |
| Developer | Konami |
| Players | 1 |
| Peripherals | Famicom Controller |
Cart Properties
| Cart Producer | Konami |
|---|---|
| Color | Black |
| Form Factor | Large |
| Embossed Text | |
| Front Label ID | RC851 |
| Seal of Quality | |
| MfgString Present | |
| 2-digit Code |
PCB Properties
| Name | 352402 |
|---|---|
| PCB Producer | Konami |
| Manufacturer | Not Specified |
| Mfg Range | 9111 - 9111 (2) |
| Est First Run | March 1991 |
| PCB Class | KONAMI-VRC-7 |
| iNES Mapper | 85 |
| Mirroring | Mapper Ctrl |
| Battery present | Yes |
| WRAM | 8 KB |
| VRAM | 8 KB |
| CIC Type | None |
| Hardware | MM1026, VRC7 |
ROM Details
| Type | Label | Size | CRC32 | x ! |
|---|---|---|---|---|
| PRG0 | RC851J00P | 512 KB | 743387FF | 2 |
Detailed Chip Info
| Designation | Maker | Part # | Type | Package | Date Code | Std | Misc |
|---|---|---|---|---|---|---|---|
| Sharp | LH5341 | Mask ROM 512 KB | DIP-32 | 9111 D | 9111 | ||
| LSI Logic | LH5160F-10TL | SRAM 8 KB | DIP-28 | 043 D | 9043 | ||
| _UnkAMS | 053982 VRC VII | Konami VRC VII | DIP-48 | 9049 IATD | 9049 | ||
| Mitsumi | 1026B | MM1026 | DIP-8 | 12 7 | 9106 | ||
| Fujitsu | MB8464A-15LL-SK | SRAM 8 KB | SDIP-28 | 9102 KT10 | 9102 |
