Release Info
| Catalog ID | HVC-BS |
|---|---|
| Region | Japan (NTSC) |
| Class | Licensed |
| Release Date | June 21, 1984 |
| Publisher | Nintendo |
| Developer | Hudson Soft |
| Players | 1 |
| Peripherals | Family Keyboard,Famicom Controller |
Cart Properties
| Cart Producer | |
|---|---|
| Color | Black |
| Form Factor | Family Basic |
| Embossed Text | |
| Front Label ID | Not Present |
| Seal of Quality | |
| MfgString Present | |
| 2-digit Code |
PCB Properties
| Name | FB-N-128-02 |
|---|---|
| PCB Producer | Nintendo |
| Manufacturer | Not Specified |
| Mfg Range | 8431 - 8442 (3) |
| Est First Run | August 1984 |
| PCB Class | HVC-FAMILYBASIC |
| iNES Mapper | 0 |
| Mirroring | Vertical |
| Battery present | Yes |
| WRAM | 2 KB |
| VRAM | 0 KB |
| CIC Type | None |
| Hardware | 74xx20 |
ROM Details
| Type | Label | Size | CRC32 | x ! |
|---|---|---|---|---|
| PRG1 | HVC-FB1-2 B | 16 KB | 9FBFB6BA | 1 |
| PRG0 | HVC-FB1-2 A | 16 KB | 1048E43D | 1 |
| CHR0 | HVC-FB1-0 C | 8 KB | 11848B93 | 4 |
| N/A | ROMs Combined | 40 KB | 895037BC | 1 |
Detailed Chip Info
| Designation | Maker | Part # | Type | Package | Date Code | Std | Misc |
|---|---|---|---|---|---|---|---|
| IC1 WORKING RAM | Fujitsu | MB8416A-15-SK | SRAM 2 KB | SDIP-24 | 8432 G17 | 8432 | |
| IC2 PROGRAM ROM-A 128K | VTI | 23128 1246 | Mask ROM 16 KB | DIP-28 | 437 VA 4415 | 8437 | RP23128 0541 |
| IC3 PROGRAM ROM-B 128K | VTI | 23128 1247 | Mask ROM 16 KB | DIP-28 | 437 VA 4391 | 8437 | RP23128 0542 |
| IC4 LS20 | Toshiba | TC74HC20P | 74-20 Series | DIP-14 | 8431 H | 8431 | |
| IC5 CHARACTER ROM-C 64K | Ricoh | RP2D70 0032 | Mask ROM 8 KB | DIP-28 | 4K3 24 | 8442 |
