Release Info
| Catalog ID | NES-BB-ESP |
|---|---|
| Region | Spain (PAL-B) |
| Class | Licensed |
| Release Date | March 1, 1993 |
| Publisher | Loriciel |
| Developer | Loriciel |
| Players | 2 |
| Peripherals | NES Controller |
Cart Properties
| Cart Producer | Nintendo (NES) |
|---|---|
| Color | Grey |
| Form Factor | 3-Screw |
| Embossed Text | Nintendo® Pat. Pend. Made in Japan |
| Front Label ID | NES-BB-ESP |
| Seal of Quality | PAL: Round (Original) |
| MfgString Present | Yes |
| 2-digit Code | 08 |
PCB Properties
| Name | NES-UOROM-02 |
|---|---|
| PCB Producer | Nintendo |
| Manufacturer | Not Specified |
| Mfg Range | 9309 |
| Est First Run | March 1993 |
| PCB Class | NES-UOROM |
| iNES Mapper | 2 |
| Mirroring | Vertical |
| Battery present | No |
| WRAM | 0 KB |
| VRAM | 8 KB |
| CIC Type | 3195A |
| Hardware | 74xx161, 74xx32 |
ROM Details
| Type | Label | Size | CRC32 | x ! |
|---|---|---|---|---|
| PRG0 | PAL-BB-0 PRG | 256 KB | BD339E75 | 1 |
Detailed Chip Info
| Designation | Maker | Part # | Type | Package | Date Code | Std | Misc |
|---|---|---|---|---|---|---|---|
| U1 PRG | Sharp | LH532J 2L | Mask ROM 256 KB | DIP-32 | 9309 E | 9309 | |
| U2 CHR RAM | NEC | 64S20 | SRAM 8 KB | DIP-28 | 9217 EJ | 9217 | |
| U3 CIC | Sharp | 3195A | Nintendo CIC | DIP-16 | 9211 A | 9211 | |
| U4 74HC161 | GoldStar | GD74HC161 | 74-161 Series | DIP-16 | 9248 | 9248 | |
| U5 74HC32 | GoldStar | GD74HC32 | 74-32 Series | DIP-14 | 9152 | 9152 |
