Release Info
| Catalog ID | NES-PW-FRA |
|---|---|
| Region | France (PAL-B) |
| Class | Licensed |
| Release Date | September 15, 1987 |
| Publisher | Nintendo |
| Developer | Human Entertainment |
| Players | 2 |
| Peripherals | NES Controller |
Cart Properties
| Cart Producer | Nintendo (NES) |
|---|---|
| Color | Grey |
| Form Factor | 5-Screw |
| Embossed Text | Nintendo® Pat. Pend. Made in Japan |
| Front Label ID | FRA |
| Seal of Quality | Round |
| MfgString Present | No |
| 2-digit Code |
PCB Properties
| Name | NES-UN-ROM-04 |
|---|---|
| PCB Producer | Nintendo |
| Manufacturer | Not Specified |
| Mfg Range | 8738 - 8738 (2) |
| Est First Run | September 1987 |
| PCB Class | NES-UNROM |
| iNES Mapper | 2 |
| Mirroring | Vertical |
| Battery present | No |
| WRAM | 0 KB |
| VRAM | 8 KB |
| CIC Type | 3195A |
| Hardware | 74xx161, 74xx32 |
ROM Details
| Type | Label | Size | CRC32 | x ! |
|---|---|---|---|---|
| PRG0 | PAL-PW-0 PRG | 128 KB | 38DE7053 | 5 |
Detailed Chip Info
| Designation | Maker | Part # | Type | Package | Date Code | Std | Misc |
|---|---|---|---|---|---|---|---|
| PRG ROM | Sharp | LH2310 54 | Mask ROM 128 KB | DIP-28 | 8738 D | 8738 | |
| CHR RAM | NEC | 64S20 | SRAM 8 KB | DIP-28 | 8735 MU | 8735 | |
| CIC | Sharp | 3195A | Nintendo CIC | DIP-16 | 8734 A | 8734 | |
| LS161N | Sharp | LR74HC161 | 74-161 Series | DIP-16 | 8732 CA | 8732 | |
| LS32 | Toshiba | 74HC32AP | 74-32 Series | DIP-14 | 8730 H | 8730 |
