Release Info
| Catalog ID |
AVE-WB |
| Region |
USA (NTSC) |
| Class |
Unlicensed |
| Release Date |
1990 |
| Publisher |
AVE |
| Developer |
AGCI |
| Players |
2 |
| Peripherals |
NES Controller |
Cart Properties
| Cart Producer |
AVE |
| Color |
Black |
| Form Factor |
Cut Corner |
| Embossed Text |
None |
| Front Label ID |
|
| Seal of Quality |
|
| MfgString Present |
|
| 2-digit Code |
|
PCB Properties
| Name |
NINA-07 |
| PCB Producer |
AVE |
| Manufacturer |
ACL |
| Mfg Range |
9119 - 9119 (2) |
| Est First Run |
May 1991 |
| PCB Class |
AVE-NINA-07 |
| iNES Mapper |
11 |
| Mirroring |
Vertical |
| Battery present |
No |
| WRAM |
0 KB |
| VRAM |
8 KB |
| CIC Type |
CIC Stun |
| Hardware |
74xx377 |
ROM Details
| Type |
Label |
Size |
CRC32 |
x ! |
| PRG0 |
WALLY BEAR |
128 KB |
81ECDA0D |
2 |
Detailed Chip Info
| Designation |
Maker |
Part # |
Type |
Package |
Date Code |
Std |
Misc |
| U1 |
GoldStar |
GM76C88-10
|
SRAM
8 KB
|
DIP-28 |
I20
|
8920 |
|
| U2 |
IMP |
IM231003
|
Mask ROM
128 KB
|
DIP-32 |
9119
NEF
|
9119 |
|
| U4 |
SGS |
T74LS377B1
|
74-377 Series
|
DIP-20 |
8622
9
|
8622 |
|
Additional Images
PCB Images
