Release Info
| Catalog ID | NES-UK-USA |
|---|---|
| Region | USA (NTSC) |
| Class | Licensed |
| Release Date | September 1989 |
| Publisher | Capcom |
| Developer | Capcom |
| Players | 1 |
| Peripherals | NES Controller |
Cart Properties
| Cart Producer | Nintendo (NES) |
|---|---|
| Color | Grey |
| Form Factor | 3-Screw |
| Embossed Text | Nintendo® Pat. Pend. Made in Japan |
| Front Label ID | Not Present |
| Seal of Quality | None |
| MfgString Present | No |
| 2-digit Code |
PCB Properties
| Name | NES-UNROM-08 |
|---|---|
| PCB Producer | Nintendo |
| Manufacturer | Not Specified |
| Mfg Range | 8938 - 8948 (3) |
| Est First Run | September 1989 |
| PCB Class | NES-UNROM |
| iNES Mapper | 2 |
| Mirroring | Vertical |
| Battery present | No |
| WRAM | 0 KB |
| VRAM | 8 KB |
| CIC Type | 6113B1 |
| Hardware | 74xx161, 74xx32 |
ROM Details
| Type | Label | Size | CRC32 | x ! |
|---|---|---|---|---|
| PRG0 | DUCK NEC CAPCOM | 128 KB | FF53D73E | 1 |
Detailed Chip Info
| Designation | Maker | Part # | Type | Package | Date Code | Std | Misc |
|---|---|---|---|---|---|---|---|
| U1 PRG | __Unknown | 27C1000 | UV EPROM 128 KB | DIP-32 | |||
| U2 CHR RAM | __Unknown | 6264 | SRAM 8 KB | DIP-28 | |||
| U3 CIC | Sharp | 6113B1 | Nintendo CIC | DIP-16 | |||
| U4 HC161 | __Unknown | 74161 | 74-161 Series | DIP-16 | |||
| U5 HC32 | __Unknown | 7432 | 74-32 Series | DIP-14 |
