Release Info
| Catalog ID | TEC-RI |
|---|---|
| Region | Japan (NTSC) |
| Class | Licensed |
| Release Date | January 23, 1988 |
| Publisher | Sunsoft |
| Developer | Sunsoft |
| Players | 1 |
| Peripherals | Famicom Controller |
Cart Properties
| Cart Producer | Nintendo (Famicom) |
|---|---|
| Color | White |
| Form Factor | Small |
| Embossed Text | |
| Front Label ID | TEC-RI |
| Seal of Quality | |
| MfgString Present | |
| 2-digit Code | 05 |
PCB Properties
| Name | HVC-SGROM-02 |
|---|---|
| PCB Producer | Nintendo |
| Manufacturer | Not Specified |
| Mfg Range | 8753 |
| Est First Run | January 1988 |
| PCB Class | HVC-SGROM |
| iNES Mapper | 1 |
| Mirroring | Mapper Ctrl |
| Battery present | No |
| WRAM | 0 KB |
| VRAM | 8 KB |
| CIC Type | None |
| Hardware | MMC1A |
ROM Details
| Type | Label | Size | CRC32 | x ! |
|---|---|---|---|---|
| PRG0 | TEC-RI-0 PRG | 128 KB | A38857EB | 1 |
Detailed Chip Info
| Designation | Maker | Part # | Type | Package | Date Code | Std | Misc |
|---|---|---|---|---|---|---|---|
| NEC | UPD23C1010 | Mask ROM 128 KB | DIP-28 | 8752 EX | 8752 | ||
| Toshiba | TC5563APL-15 | SRAM 8 KB | SDIP-28 | 8634 HBK | 8634 | ||
| Sharp | MMC1A | Nintendo MMC1 | DIP-24 | 8753 A | 8753 |
