Release Info
| Catalog ID | NBF-AU (06) |
|---|---|
| Region | Japan (NTSC) |
| Class | Licensed |
| Release Date | November 13, 1987 |
| Publisher | Nichibutsu |
| Developer | Nichibutsu |
| Players | 1 |
| Peripherals | Famicom Controller |
Cart Properties
| Cart Producer | Nintendo (Famicom) |
|---|---|
| Color | White |
| Form Factor | Small |
| Embossed Text | |
| Front Label ID | NBF-AU |
| Seal of Quality | |
| MfgString Present | |
| 2-digit Code | 00 |
PCB Properties
| Name | HVC-SJROM-01 |
|---|---|
| PCB Producer | Nintendo |
| Manufacturer | Not Specified |
| Mfg Range | 8742 - 8743 (3) |
| Est First Run | October 1987 |
| PCB Class | HVC-SJROM |
| iNES Mapper | 1 |
| Mirroring | Mapper Ctrl |
| Battery present | Yes |
| WRAM | 8 KB |
| VRAM | 0 KB |
| CIC Type | None |
| Hardware | MMC1 |
ROM Details
| Type | Label | Size | CRC32 | x ! |
|---|---|---|---|---|
| PRG0 | NBF-AU-0 PRG | 128 KB | EBAC24E9 | 3 |
| CHR0 | NBF-AU-0 CHR | 32 KB | 07F2131B | 3 |
| N/A | ROMs Combined | 160 KB | 093E845F | 3 |
Detailed Chip Info
| Designation | Maker | Part # | Type | Package | Date Code | Std | Misc |
|---|---|---|---|---|---|---|---|
| PRG | Sharp | LH2310 5S | Mask ROM 128 KB | DIP-28 | 8743 D | 8743 | |
| CHR | Sharp | LH2359 28 | Mask ROM 32 KB | DIP-28 | 8743 E | 8743 | |
| MMC1 | Sharp | MMC1 | Nintendo MMC1 | DIP-24 | 8741 A | 8741 | |
| W-RAM | Sony | CXK5864PN-15LL | SRAM 8 KB | DIP-28 | 7H 15 | 8731 |
