Release Info
| Catalog ID | BA-FJ2 |
|---|---|
| Region | Japan (NTSC) |
| Class | Licensed » 3rd-Party |
| Release Date | December 2, 1991 |
| Publisher | Bandai |
| Developer | Chunsoft |
| Players | 1 |
| Peripherals | Famicom Controller |
Cart Properties
| Cart Producer | Bandai |
|---|---|
| Color | Black |
| Form Factor | Large |
| Embossed Text | © Bandai 19xx Made in Japan |
| Front Label ID | |
| Seal of Quality | |
| MfgString Present | |
| 2-digit Code |
PCB Properties
| Name | BA-JUMP2 |
|---|---|
| PCB Producer | Bandai |
| Manufacturer | Not Specified |
| Mfg Range | 9149 - 9149 (2) |
| Est First Run | December 1991 |
| PCB Class | BANDAI-JUMP2 |
| iNES Mapper | 16 |
| Mirroring | Mapper Ctrl |
| Battery present | Yes |
| WRAM | 8 KB |
| VRAM | 8 KB |
| CIC Type | None |
| Hardware | FCG-3 |
ROM Details
| Type | Label | Size | CRC32 | x ! |
|---|---|---|---|---|
| PRG0 | BANDAI'91 JUMP-2 | 512 KB | 3F15D20D | 2 |
Detailed Chip Info
| Designation | Maker | Part # | Type | Package | Date Code | Std | Misc |
|---|---|---|---|---|---|---|---|
| Sharp | LH5341 | Mask ROM 512 KB | DIP-32 | 9149 D | 9149 | ||
| Sharp | LH5160YF-10L | SRAM 8 KB | DIP-28 | 043 B | 9043 | ||
| Sharp | LH5160YF-10L | SRAM 8 KB | DIP-28 | 043 B | 9043 | ||
| Sharp | LZ93D50 | Bandai FCG-3 | DIP-52 | 9124 3 A | 9124 |
