Release Info
| Catalog ID | NES-CM-USA |
|---|---|
| Region | USA (NTSC) |
| Class | Licensed |
| Release Date | December 1988 |
| Publisher | Capcom |
| Developer | Capcom |
| Players | 1 |
| Peripherals | NES Controller |
Cart Properties
| Cart Producer | Nintendo (NES) |
|---|---|
| Color | Grey |
| Form Factor | 3-Screw |
| Embossed Text | Nintendo® Pat. Pend. Made in Japan |
| Front Label ID | NES-CM-USA |
| Seal of Quality | Oval (TM) |
| MfgString Present | Yes |
| 2-digit Code | 12 |
PCB Properties
| Name | NES-SGROM-02 |
|---|---|
| PCB Producer | Nintendo |
| Manufacturer | Not Specified |
| Mfg Range | 8916 - 8939 (2) |
| Est First Run | April 1989 |
| PCB Class | NES-SGROM |
| iNES Mapper | 1 |
| Mirroring | Mapper Ctrl |
| Battery present | No |
| WRAM | 0 KB |
| VRAM | 8 KB |
| CIC Type | 6113B1 |
| Hardware | MMC1A |
ROM Details
| Type | Label | Size | CRC32 | x ! |
|---|---|---|---|---|
| PRG0 | NES-CM-0 PRG | 256 KB | D2574720 | 3 |
Detailed Chip Info
| Designation | Maker | Part # | Type | Package | Date Code | Std | Misc |
|---|---|---|---|---|---|---|---|
| IC1 PRG-ROM | NEC | UPD23C2013 | Mask ROM 256 KB | DIP-32 | 8915 EY | 8915 | |
| IC2 CHR-RAM | Fujitsu | MB8464A-15L-SK | SRAM 8 KB | SDIP-28 | 8910 KT76 | 8910 | |
| IC3 MMC | Sharp | MMC1A | Nintendo MMC1 | DIP-24 | 8912 1 A | 8912 | |
| IC4 CIC | Sharp | 6113B1 | Nintendo CIC | DIP-16 | 8916 3 AA | 8916 |
